The SY265C provides optimal jobsite safety thanks to its combination of safety features.
+ ROPS/TOPS certified cab for safe operation
+ Rear and side view camera for panoramic visibility
+ Travel alarm, green seat belt and rotating warning beacon to increase visibility, attract attention and ensure safety
+ LED work lights for maximum visibility in low light conditions
The SY265C provides the kind of comfort that operators appreciate!
+ Ergonomic and fully adjustable, heated operator’s seat
+ Clear instrumentation and large high resolution colour display
+ Adjustable ventilation, heating and automatic climate control system
+ Integrated cooling box and large amount of storage space
+ Radio, speaker and USB port
+ Easy access to all maintenance points
+ Low maintenance requirements and longer service intervals
+ Ergonomic handrails and anti-slip tread surfaces allow safe access to the maintenance platform
+ Registered and protected with the CESAR Datatag Scheme (the premier initiative against equipment theft) and CESAR ECV for quick and easy verification of emissions category
+ SANY EVI telematics technology is used to monitor a wide
range of information relating to an individual machine or
an entire fleet. Data is gathered by the onboard controllers
on SANY machines to keep data transferring throughout the
day. If you have a mixed fleet with other OEMs, you can
easily access data for your SANY equipment and other brands
using a telematics API, together in one management system.
+ 5-year/5000 hour warranty as standard for complete peace of mind (Terms and Conditions apply)
|
DIMENSIONS
|
|
|
Transport length
|
10,290 mm
|
|
Transport width
|
3,290 mm
|
|
Transport height
|
3,225 mm
|
|
Upper structure carriage
|
3,045 mm
|
|
Height over cabin/ROPS
|
3,040 mm
|
|
Height of Boom – transport
|
3,365 mm
|
|
Overall length of crawler
|
4,636 mm
|
|
Track gauge
|
2,590 mm
|
|
Track height
|
945 mm
|
|
Track pads width
|
Standard 700 mm. Optional 600 mm or 800 mm
|
|
Minimum ground clearance
|
470 mm
|
|
Counterweight clearance
|
1,045 mm
|
|
Engine cover height
|
2,640 mm
|
|
Tail swing radius
|
3,105 mm
|
|
Centre distance of tumblers
|
3,833 mm
|
|
Ground pressure
|
39.3 KPa
|
|
|
|
|
WEIGHT
|
|
|
Operating weight
|
27,000 kg
|
|
|
|
ENGINE
|
|
Model
|
Cummins QSB 6.7 – 6 cylinder
|
|
Rated power
|
145 kw
|
|
Max. Torque
|
1472 Nm
|
|
Displacement
|
6.7 l
|
|
Exhaust emissions
|
Stage V
|
|
Batteries
|
24 v
|
|
|
|
HYDRAULIC SYSTEM
|
|
Max. Oil flow
|
2x 260 l/min
|
|
|
|
RELIEF VALVE SETTING
|
|
Implement circuit
|
34.3 MPa
|
|
Power boost
|
37.3 MPa
|
|
Swing circuit
|
29 MPa
|
|
Travel circuit
|
34.3 MPa
|
|
Pilot pressure
|
3.9 MPa
|
|
|
|
SERVICE REFILL CAPACITIES
|
|
Fuel tank
|
465 l
|
|
Engine coolant
|
40 l
|
|
Engine oil
|
27 l
|
|
Drive (per side)
|
7.8 l
|
|
Hydraulic oil tank
|
275 l
|
|
AdBlue
|
38 l
|
|
|
|
PERFORMANCE
|
|
Swing speed
|
10.6 rpm
|
|
Travel speed (Low/High)
|
3.7/5.5 km/h
|
|
Max. travel force
|
227 kN
|
|
Gradeability
|
70%*(35°)
|
|
Bucket digging force ISO
|
187 kN
|
|
Arm digging force ISO
|
130 kN
|
|
Boom length
|
5,900 mm
|
|
Arm length
|
2,950 mm
|
|
Bottom rollers
|
9
|
|
Top rollers
|
2
|
|
|
|
WORKING RANGE
|
|
Max. digging reach
|
10,225 mm
|
|
Max. digging depth
|
6,705 mm
|
|
Max. digging Height
|
9,750 mm
|
|
Max. dumping height
|
6,715 mm
|
|
Max. vertical digging depth
|
5,675 mm
|
|
Overall height over arm by Min . swing radius
|
8,020 mm
|
|
Min. swing radius
|
3,880 mm
|
