The SY35E is equipped with a number of safety features, all included as standard.
+ ROPS/TOPS certified for safe operation.
+ Excellent visibility for increased site safety.
+ Battery disconnect switch and emergency stop button.
+ Travel alarm and green beacon as standard for enhanced visibility and safety.
With the SY35E operators can look forward to maximum comfort and easy operation.
+ Very low noise levels for operator comfort and onsite communication clarity.
+ Simplified charging solution with single charge port and minimal cables or adaptors.
+ Responsive and precise controls with ergonomic operator seat and adjustable armrests.
+ Large high-resolution display, keyless push start/stop and password protection.
+ LED work lights positioned on boom and front for maximum visibility in low light.
+ Easy access to all maintenance points.
+ Fully electric drive with fewer moving parts and significantly reduced service requirements – servicing costs lowered by up to 80%.
+ Maintenance-free lithium iron phosphate battery with BMS and thermal management ensures battery performance and longevity.
+ Registered to CESAR Datatag Scheme (for equipment theft protection) and CESAR ECV for emissions category verification.
+ EVI telematics with built-in tracker for machine monitoring and added peace of mind.
+ SANY EVI telematics technology is used to monitor a wide
range of information relating to an individual machine or
an entire fleet. Data is gathered by the onboard controllers
on SANY machines to keep data transferring throughout the
day. If you have a mixed fleet with other OEMs, you can
easily access data for your SANY equipment and other brands
using a telematics API, together in one management system.
+ 5-year / 5,000 hour warranty as standard (terms & conditions apply).
|
BATTERY
|
|
|
Battery type
|
Lithium iron phosphate battery (cobalt free)
|
|
Rated voltage
|
405.72 v
|
|
Rated battery capacity
|
173 Ah
|
|
Run time
|
5 – 7 hrs
|
|
Charge time
|
DC 1hr / Industrial (360v) 6hrs / Domestic (240v) 9hrs
|
|
|
|
|
DIMENSIONS
|
|
|
Transport length
|
4,920 mm
|
|
Transport width
|
1,720 mm
|
|
Transport height
|
2,615 mm
|
|
Cab width
|
1000 mm
|
|
Blade height
|
375 mm
|
|
Standard track pad width
|
300 mm
|
|
Track gauge
|
1,420 mm
|
|
Tail swing radius
|
1,100 mm
|
|
Track ground length
|
1,670 mm
|
|
Track length
|
2,155 mm
|
|
Counterweight ground clearance
|
295 mm
|
|
Bucket capacity
|
0.12m3
|
|
|
|
|
WORKING RANGE
|
|
|
Maximum digging height
|
4,865 mm
|
|
Maximum dumping height
|
3,445 mm
|
|
Maximum digging depth
|
3,115 mm
|
|
Maximum vertical digging depth
|
2,640 mm
|
|
Maximum digging reach
|
5,480 mm
|
|
Minimum swing radius
|
2,475 mm
|
|
Blade max height
|
375 mm
|
|
Blade max depth
|
370 mm
|
|
|
|
|
WEIGHT
|
|
|
Operating weight
|
4,300 kg
|
|
|
|
|
HYDRAULIC SYSTEM
|
|
|
Main pump
|
Variable displacement axial piston pumps with a load-sensing hydraulic system
|
|
Maximum oil flow
|
88 l/m
|
|
Main rotary drive
|
28 MPa
|
|
|
|
|
|
|
|
PERFORMANCE
|
|
|
Power
|
18 Kw (Peak) / 10 Kw (Continuous)
|
|
Traveling speed (High-Low)
|
4.2/2.4 km/h
|
|
Swing speed
|
10 rpm
|
|
Gradeability
|
58% /30°
|
|
Max system flow
|
88 l/m
|
|
Bucket digging force
|
26.51 kN
|
|
Arm digging force
|
19.96kN
|
|
Noise
|
68/91 dB
|
