The SY750H includes a combination of safety features that work together to minimise risks to those people in and around the machine.
+ ROPS/TOPS certified cab for safe operation
+ Rear and side view camera for panoramic visibility
+ Travel alarm, green seat belt and rotating warning beacon to increase visibility, attract attention and ensure safety
+ LED work lights positioned on the boom, front and side of the cab for maximum visibility in low light conditions
The ergonomically designed operators cab of the SY750H ensures both comfort, convenience and maximum productivity.
+ Deluxe, ergonomic and fully adjustable, heated operator’s seat
+ Clear instrumentation and large 10.4″ high resolution colour display
+ Adjustable ventilation, heating and automatic climate control system
+ Integrated cooling box and large amount of storage space
+ Radio, USB charging port and Bluetooth connectivity
+ Easy access to all maintenance points
+ Low maintenance requirements and longer service intervals
+ Ergonomic handrails and anti-slip tread surfaces allow safe access to the maintenance platform
+ Registered and protected with the CESAR Datatag Scheme (the premier initiative against equipment theft) and CESAR ECV for quick and easy verification of emissions category
+ SANY EVI telematics technology is used to monitor a wide
range of information relating to an individual machine or
an entire fleet. Data is gathered by the onboard controllers
on SANY machines to keep data transferring throughout the
day. If you have a mixed fleet with other OEMs, you can
easily access data for your SANY equipment and other brands
using a telematics API, together in one management system.
+ 5-year/5000 hour warranty as standard for complete peace of mind (Terms and Conditions apply)
|
DIMENSIONS
|
|
|
Transport Length
|
12879 mm
|
|
Transport Width
|
3499 mm
|
|
Transport Height
|
4981 mm
|
|
Upper Structure Width (with step)
|
4479 mm
|
|
Cab Height
|
3795 mm
|
|
Track Width (standard shoe)
|
650 mm
|
|
Track Gauge
|
3380 mm
|
|
Ground Clearance
|
892 mm
|
|
Tailswing Radius
|
4175 mm
|
|
Track Length on Ground
|
4770 mm
|
|
Track Length
|
5986 mm
|
|
|
|
|
WORKING RANGE
|
|
|
Maximum Digging Height
|
11020 mm
|
|
Maximum Dumping Height
|
7170 mm
|
|
Maximum Digging Depth
|
7580 mm
|
|
Maximum Vertical Wall Digging Depth
|
4890 mm
|
|
Maximum Reach at Ground Level
|
12100 mm
|
|
Minimum Swing Radius
|
5390 mm
|
|
Bucket Breakout Force (ISO)
|
410.0 kN
|
|
Stick (Arm) Digging Force (ISO)
|
354.0 kN
|
|
|
|
|
WEIGHT
|
|
|
Operating weight
|
80,850 kg
|
|
|
|
|
ENGINE
|
|
|
Model
|
Cummins X15
|
|
Gross Power
|
391 kW
|
|
|
|
|
RELIEF VALVE SETTING
|
|
|
Operating Flow (maximum) 2@504 L/min
|
1008 L/min
|
|
Operating Pressure (maximum)
|
34.3 MPa
|
|
Travel Pressure
|
34.3 Mpa
|
|
Slew Pressure
|
28.5 Mpa
|
|
Pilot Pressure
|
3.9 Mpa
|
|
|
|
|
SERVICE REFILL CAPACITIES
|
|
|
Tank
|
940 l
|
|
Engine coolant
|
75 l
|
|
Engine oil
|
39 l
|
|
Hydraulic tank
|
680 l
|
|
DEF tank
|
100 l
|
