The SY500H includes a combination of safety features that work together to minimise risks to those people in and around the machine.
+ ROPS/TOPS certified cab for safe operation
+ Rear and side view camera for panoramic visibility
+ Travel alarm, green seat belt and rotating warning beacon to increase visibility, attract attention and ensure safety
+ LED work lights for maximum visibility in low light conditions
The ergonomically designed operators cab of the SY500H ensures both comfort, convenience and maximum productivity.
+ Ergonomic and fully adjustable, heated operator’s seat
+ Clear instrumentation and large high resolution colour display
+ Adjustable ventilation, heating and automatic climate control system
+ Integrated cooling box and large amount of storage space
+ Radio, speaker and USB port
+ Easy access to all maintenance points
+ Low maintenance requirements and longer service intervals
+ Ergonomic handrails and anti-slip tread surfaces allow safe access to the maintenance platform
+ Registered and protected with the CESAR Datatag Scheme (the premier initiative against equipment theft) and CESAR ECV for quick and easy verification of emissions category
+ SANY EVI telematics technology is used to monitor a wide range of information relating to an individual machine or an entire fleet. Data is gathered by the onboard controllers on SANY machines to keep data transferring throughout the day. If you have a mixed fleet with other OEMs, you can easily access data for your SANY equipment and other brands, using a telematics API, together in one management system.
+ 5-year/5000 hour warranty as standard for complete peace of mind (Terms and Conditions apply)
|
DIMENSIONS
|
|
|
Transport Length
|
12,100 mm
|
|
Transport width
|
3,700 mm
|
|
Upperstructure carriage
|
3,300 mm
|
|
Height over cabin
|
3,480 mm
|
|
Height of Boom – transport
|
3,600 mm
|
|
Overall length of crawler
|
5,460 mm
|
|
Tail length
|
3,740 mm
|
|
Track gauge
|
2,740 mm
|
|
Track height
|
1,220 mm
|
|
Track pads width
|
600 mm
|
|
Min. ground clearance
|
560 mm
|
|
Counterweight clearance
|
1 355 mm
|
|
Engine cover height
|
3 160 mm
|
|
Tail swing radius
|
3 740 mm
|
|
Center distance of tumblers
|
4 410 mm
|
|
|
|
|
PERFORMANCE
|
|
|
Bucket Breakout Force (ISO)
|
260.0 kN
|
|
Stick (Arm) Digging Force (ISO)
|
230.0 kN
|
|
|
|
|
WORKING RANGE
|
|
|
Max. digging reach
|
12,035 mm
|
|
Max. digging depth
|
7,705 mm
|
|
Max. digging height
|
10,930 mm
|
|
Max. dumping height
|
7,650 mm
|
|
Max. vertical digging depth
|
6,280 mm
|
|
Min. swing radius
|
521 mm
|
|
|
|
|
WEIGHT
|
|
|
Operating weight
|
53,300 kg
|
|
|
|
|
ENGINE
|
|
|
Model
|
Cummins X12
|
|
Rated power
|
298 kW / 2 100 rpm
|
|
|
|
|
RELIEF VALVE SETTING
|
|
|
Implement circuit
|
350 bar
|
|
Power boost
|
370 bar
|
|
Swing circuit
|
270 bar
|
|
Travle circuit
|
350 bar
|
|
Pilot pressure
|
40 bar
|
|
|
|
|
SERVICE REFILL CAPACITIES
|
|
|
Fuel tank
|
680 l
|
|
Engine coolant
|
50 l
|
|
Engine oil
|
34 l
|
|
Drive (per side)
|
15 l
|
|
Adblue
|
46 l
|
|
Hydraulic oil tank
|
480 l
|
